SIMPLE OPERATION:
An intuitive menu-driven
control system provides
comprehensive installation,
configuration and operational
information via the front
panel LCD display. Critical
operating functions are
automatically monitored and
audible and visual signals
notify users of conditions
requiring immediate action. |
SIMPLE TAPE
MANAGEMENT
Tapes are housed in convenient
removable magazines
that simply snap in and out
of the TeraLoader. Removing
and organizing tapes for
offsite storage has never
been easier. Barcode
scanning is built-in. |
SIMPLE SYSTEM MANAGEMENT WITH Q-LINK
Every TeraLoader comes with Q-Link, Qualstar’s unique browser-based remote
library manager. Q-Link enables administrators to configure, monitor and manage
a TeraLoader from across the room, or across the world over the Internet.
All of the information, functions and controls built into the Teraloader’s powerful
menu system are replicated remotely by Q-Link! With Q-Link, administrators can
deploy and manage multiple TeraLoaders from one central location, providing
true distributed data protection without increasing cost. Even firmware updates
can be performed remotely. |
VERSATILITY
• Ultra2 LVD SCSI interface
• Rackmount slides included
• Supported by all major
software application packages
• Barcode reader included
ENGINEERED
FOR RELIABILITY
• All brushless motors
• Self-calibrating all-digital
servo control system
• Over 2,000,000 MEBF |
b) TECH SPECS
Model |
Tape Technology |
Cartridges |
Native Capacity |
RLS-4124 |
AIT-3 |
24 |
2.4 Terabytes |
RLS-5116 |
SAIT |
16 |
8.0 Terabytes |
RLS-8116 |
LTO 2 |
16 |
3.2 Terabytes |
| 1) TERALOADER LTO MODELS |
Model RLS-8116 |
LTO 2 |
LTO 3 |
Native Capacity |
3.2 Terabytes |
6.4 Terabytes |
Capacity with Compression |
6.4 Terabytes |
12.8 Terabytes |
Native Data Rate |
126 GB/hr |
288 GB/hr |
Data Rate with Compression |
252 GB/hr |
576 GB/hr |
| 2) TERALOADER AIT MODELS |
Model RLS-4124 |
AIT-3 |
AIT-4 |
Native Capacity |
2.4 Terabytes |
4.8 Terabytes |
Capacity with Compression |
6.2 Terabytes |
12.4 Terabytes |
Native Data Rate |
43.2 GB/hr |
86.4 GB/hr |
Data Rate with Compression |
112.2 GB/hr |
224.4 GB/hr |
| 3) TERALOADER SAIT MODELS |
Model RLS-5116 |
SAIT |
Native Capacity |
8 Terabytes |
Capacity with Compression |
20.8 Terabytes |
Native Data Rate |
108 GB/hr |
Data Rate with Compression |
280.8 GB/hr |
|
